Design of Inter-satellite Separation of China’s First All-electric Communication Satellite

doi:10.12382/bgxb.2024.0880

Abstract

Abstract:

AP-6E satellite is the first domestic all-electric communication satellite,which is also the first communication satellite in the world to realize the autonomous orbit transfer from low earth orbit to geosynchronous orbit.The separable propulsion segment is utilized to realize the rapid orbit transfer via the chemical propulsion system,then the segment is separated and de-orbited,finally the remaining tasks of the satellite are preformed solely by the electric propulsion system.Therefore,the inter-satellite separation is the key to the success of this mission.The design of the connection and separation mechanism of AP-6E is introduced,and the stress margin of connection and the near-field and far-field safeties of separation process analyzed in order to systematically expound the experience of the engineering practice of the all-electric propulsion platform carried by the low-cost launch vehicle,which is of certain significance for the subsequent projects.

Key words: communication satellite, separation safety, combination, all-electric propulsion, chemical propulsion, inter-satellite separation

PAN Yuqian, FANG Yaopeng, WEI Qiang, WANG Min, SUN Guopeng, LIU Cuicui, LIANG Xingang. Design of Inter-satellite Separation of China’s First All-electric Communication Satellite[J]. Acta Armamentarii, 2024, 45(S2): 146-152.

Figures/Tables 9

References 17

[1]	顾航瑜. “亚太6E”:更智能的全电推通信卫星[J]. 太空探索, 2023(3):8-13.
	GU H Y. “Asia-pacific 6E”:a smarter all-electric communication satellite[J]. Space Exploration, 2023(3):8-13. (in Chinese)
[2]	胡照, 王敏, 袁俊刚. 国外全电推进卫星平台的发展及启示[J]. 航天器环境工程, 2015, 32(5):566-570.
	HU Z, WANG M, YUAN J G. A review of the development of all-electric propulsion platform in the world[J]. Spacecraft Environment Engineering, 2015, 32(5):566-570. (in Chinese)
[3]	孙小菁, 张天平, 王小永, 等. 电推进技术在全电推进卫星平台的应用研究[J]. 真空与低温, 2015, 21(1):6-10.
	SUN X J, ZHANG T P, WANG X Y, et al. The research of electric propulsion’s appplication of electric propulsion satellite platform[J]. Vacuum and Cryogenics, 2015, 21(1):6-10. (in Chinese)
[4]	李云. 国外全电推进卫星发展分析[J]. 国际太空, 2014(3):21-23.
	LI Y. Analysis of the development of all electric propulsion satellites abroad[J]. Space International, 2014(3):21-23. (in Chinese)
[5]	周志成, 高军. 全电推进GEO卫星平台发展研究[J]. 航天器工程, 2015, 24(2):1-6.
	ZHOU Z C, GAO J. Development approach to all-electric propulsion GEO satellite platform[J]. Spacecraft Engineering, 2015, 24(2):1-6. (in Chinese)
[6]	扈延林, 毛威, 李栋, 等. 面向全电推进卫星的霍尔推进技术[J]. 空间控制技术与应用, 2017, 43(1):73-78.
	HU Y L, MAO W, LI D, et al. The hall propulsion technology oriented all-electric-propulsion satellites[J]. Aerospace Control and Application, 2017, 43(1):73-78. (in Chinese)
[7]	张天平. 国外离子和霍尔电推进技术最新进展[J]. 真空与低温, 2016, 12(4):187-193,245.
	ZHANG T P. Recent international progress in ion and hall electric propulsions[J]. Vacuum and Cryogenics, 2016, 12(4):187-193,245. (in Chinese)
[8]	Viasat Inc.. Viasat-3 americans successfully lunched[EB/OL]. May 01,2023. [2024-09-01] https://news.viasat.com/newsroom/press-releases/viasat-3-americas-successfully-launched.
[9]	MACKINNON D V, WEIGL H, MAACK L. Lockheed Martin’s A2100 spacecraft bus modernization[C]// Proceedings of the 34th AIAA International Communications Satellite Systems Conference.Reston,VA,US:AIAA, 2016.
[10]	HUGHES. JUPITER 3 satellite successfully launches,heralds the start of a new era of connectivity[EB/OL]. Norcross,GA,US:Hughes Network Systems,LLC,(2023-07-29)[2024-08-15]. https://www.hughes.com/resources/press-releases/hughes-Jupiter-3-satellite-successfully-launches-heralds-thestart-new-era.
[11]	OHB. New type of propulsion system for small GEO “Electra” variant[EB/OL].(2017-02-13) [2024-09-01]. https://www.ohb.de/en/news/2017/new-type-of-propulsion-system-for-SmallGEO-Electra-variant.
[12]	European Space Agency. ESA’s neosat programme moves into development[EB/OL].(2015-09-15)[2024-09-01]. https://www.esa.int/Applications/Connectivity_and_Secure_Communications/ESA_s_Neosat_programme_moves_into_development.
[13]	Thales Alenia Space. Thales Alenia Space to sign C/D phase of NEOSAT with European Space Agency[EB/OL].(2015-09-15)[2024-09-01]. https://www.thalesgroup.com/en/worldwide/space/press-release/thales-alenia-space-sign-cd-phase-neosat-european-space-agency.
[14]	European Space Agency. Software-defined OneSat ready for production[EB/OL].(2021-12-14)[2024-09-01]. https://www.esa.int/Applications/Connectivity_and_Secure_Communications/Software-defined_OneSat_ready_for_production.
[15]	Thales Group. Thales Alenia Space fully-digital satellite to address fast moving market needs[EB/OL].(2019-09-10)[2024-09-01]. https://www.thalesgroup.com/en/worldwide/space/press-release/thales-alenia-space-releases-fully-digital-satellite-address-fast.
[16]	RSCC. EXPRESS-AM5[EB/OL].[2024-09-01]. https://eng.rscc.ru/infrastructure/satellite/ekspress-am5-140-vd/.
[17]	李正举, 崔颖慧, 蔡亚星, 等. 国外新一代高轨通信卫星平台现状与分析[J]. 航天器工程, 2023, 32(5):128-136.
	LI Z J, CUI Y H, CAI Y X, et al. Development statusand analysis of new generation high earth orbit telecommunications satellite platform abroad[J]. Spacecraft Engineering, 2023, 32(5):128-136. (in Chinese)

工程参数	偏差范围
卫星质量	±1%
独立推进舱质量	±5%
卫星X轴方向质心偏差/mm	[-5,5]
卫星Y轴方向质心偏差/mm	[-5,5]
卫星Z轴方向质心偏差/mm	[-5,5]
独立推进舱X轴方向质心偏差/mm	[-5,5]
独立推进舱Y轴方向质心偏差/mm	[-5,5]
独立推进舱Z轴方向质心偏差/mm	[-5,5]
卫星绕X轴转动惯量	±5%
卫星绕Y轴转动惯量	±5%
卫星绕Z轴转动惯量	±5%
独立推进舱绕X轴转动惯量	±5%
独立推进舱绕Y轴转动惯量	±5%
独立推进舱绕Z轴转动惯量	±5%
组合体分离前绕X轴初始角速度/((°)·s^-1)	[-0.01,0.01]
组合体分离前绕Y轴初始角速度/((°)·s^-1)	[-0.01,0.01]
组合体分离前绕Z轴初始角速度/((°)·s^-1)	[-0.01,0.01]
分离弹簧1初始分离力	±4%
分离弹簧2初始分离力	±4%
分离弹簧…初始分离力	±4%
分离弹簧X初始分离力	±4%

工程参数	偏差范围
卫星质量	±1%
独立推进舱质量	±5%
卫星X轴方向质心偏差/mm	[-5,5]
卫星Y轴方向质心偏差/mm	[-5,5]
卫星Z轴方向质心偏差/mm	[-5,5]
独立推进舱X轴方向质心偏差/mm	[-5,5]
独立推进舱Y轴方向质心偏差/mm	[-5,5]
独立推进舱Z轴方向质心偏差/mm	[-5,5]
卫星绕X轴转动惯量	±5%
卫星绕Y轴转动惯量	±5%
卫星绕Z轴转动惯量	±5%
独立推进舱绕X轴转动惯量	±5%
独立推进舱绕Y轴转动惯量	±5%
独立推进舱绕Z轴转动惯量	±5%
组合体分离前绕X轴初始角速度/((°)·s^-1)	[-0.01,0.01]
组合体分离前绕Y轴初始角速度/((°)·s^-1)	[-0.01,0.01]
组合体分离前绕Z轴初始角速度/((°)·s^-1)	[-0.01,0.01]
分离弹簧1初始分离力	±4%
分离弹簧2初始分离力	±4%
分离弹簧…初始分离力	±4%
分离弹簧X初始分离力	±4%

关键工程参数	偏差范围	敏感度
卫星X轴方向质心偏差/mm	[-5,5]	5.1%
卫星Y轴方向质心偏差/mm	[-5,5]	6.2%
独立推进舱X轴方向质心偏差/mm	[-5,5]	8.2%
独立推进舱Y轴方向质心偏差/mm	[-5,5]	15.3%
分离弹簧1分离力	±4%	14.4%
分离弹簧2分离力	±4%	17.6%
分离弹簧…分离力	±4%	14.4%
分离弹簧X分离力	±4%	17.6%

关键工程参数	偏差范围	敏感度
卫星X轴方向质心偏差/mm	[-5,5]	5.1%
卫星Y轴方向质心偏差/mm	[-5,5]	6.2%
独立推进舱X轴方向质心偏差/mm	[-5,5]	8.2%
独立推进舱Y轴方向质心偏差/mm	[-5,5]	15.3%
分离弹簧1分离力	±4%	14.4%
分离弹簧2分离力	±4%	17.6%
分离弹簧…分离力	±4%	14.4%
分离弹簧X分离力	±4%	17.6%
